Supplied and fitted only at our workshop in Newton Abbot, Devon. Please call 01626 363311 to book in.
Rear lipped semi- flush premium parking sensors supplied and fitted
DESCRIPTION
The Steelmate PTS400EX (DP) is a premium 4 sensor rear upgradeable parking sensor kit with push fit sensors and OEM sounding speaker.
The system can be programmed to ignore tow bars, nudge bars or spare wheels.
The PTS400EX (DP) is compatible with our DS1 & DS2 visual displays and can be used as a 2 sensor front or rear system if required.
The sensor hole size is 19mm in diameter.
The visible external diameter of the sensor head is 22.9mm with a depth of 20.1mm and they have detachable cables and the option to change sensor head angle between 4 and 10 degrees with a removable angled clip on ring which is included in the kit.
SENSOR COLOUR CODING
We offer a sensor colour coding service which enables the sensors to be sprayed to match the colour of your vehicle for an additional cost.
Premium Level Rear Parking Sensors Lipped Semi - Flush, Supplied and Fitte
MAIN FEATURES
58K sensors for better coverage and excellent stability
5-stage audible warning buzzer with adjustable tone pitch and volume
Option of adding a visual display
Extendable stopping distance from 30cm to 50cm, ideal for vehicles with tow bars or rear mounted spare wheels and steps
A simple jumper change when installing allows you to select a front or rear system
Heavy rain proof design
All weather design (-40°C>+80°C)
Anti-false alarm patentTECHNICAL PARAMETERS
Voltage: 12/24V
Temperature: -40>+80°C
Input: <4W
Beep volume: 70>90dB
Range (Rear): 0.3>1.5m
Range (Front): 0.3>1.0mINCLUDED IN THE KIT
4 x 14D-15 sensor heads with 4 degree clip on heads fitted
4 x 0 degree clip on heads
4 x 10 degree clip on heads
4 x 2.7m sensor cables
1 x ECU
1 x Power loom
1 x Speaker
1 x 4m speaker/visual display extension cable
